CAB EOS User Manual

10
11
11
2 Installation
2.3 Mounting the Cutter
The cutter contained in the contents of delivery must be mounted to the printer
during the initial start-up.
1
4
5
1
3
2
Fig. 6 Mount Cutter
1. Put snap arm (5) of the cutter with the groove (4) rst into the guide on the
retainer (2).
2. Push cutter (1) down into the holders (3).
3. Fold up cutter (1) so that is snaps it at both sides of the retainer (2).

CAB EOS Specifications

General

Power Supply	100-240V AC, 50/60 Hz
Print Method	Thermal transfer
Print Width	Up to 105.6 mm (depending on model)
Interfaces	USB, Serial, Ethernet
Display	LCD
Supported Barcodes	Code 39, Code 128, UPC-A, UPC-E, EAN-8, EAN-13, Interleaved 2 of 5, Data Matrix, QR Code
Supported Operating Systems	Windows
Resolution	203 dpi
Media Width	4.33" (110 mm)
