CAB EOS User Manual

14 14
15
3.1 Structure of the Touchscreen Display
i
Notice!
It is advantageous, whenever possible, to make adaptations to
various print jobs in the software.
2
1
Ready
The touchscreen display (1) indicates the
current status of the printer and the print job,
indicates faults and shows the printer settings
in the menu.
By selecting the buttons on the touchscreen
display (1) settings can be made.
Two USB master ports (2/ I
max
= 100 mA) are
positioned under the touchscreen display (1).
Fig. 9 Touchscreen Display
3.2 Operating the Touchscreen Display
The touchscreen display is operated directly by touch:
• To open a menu or select a menu item lightly touch the corresponding
symbol.
• To scroll in lists slide nger up or down on the display.
3 Control Panel

CAB EOS Specifications

General

Power Supply	100-240V AC, 50/60 Hz
Print Method	Thermal transfer
Print Width	Up to 105.6 mm (depending on model)
Interfaces	USB, Serial, Ethernet
Display	LCD
Supported Barcodes	Code 39, Code 128, UPC-A, UPC-E, EAN-8, EAN-13, Interleaved 2 of 5, Data Matrix, QR Code
Supported Operating Systems	Windows
Resolution	203 dpi
Media Width	4.33" (110 mm)
