7.4 Cleaning or Replacing the Print Roller

Accumulations of dirt on the print roller may impair the media transport and

the print quality.

Attention!

Damage of the print roller.

 Do not use sharp objects (knives, screwdrivers, etc.) to clean

the print roller.

43 35

Fig. 18 Print Roller

1. Turn lever (2) counterclockwise to open printhead.

2. Remove material and transfer ribbon from the printer.

3. Fold down cover (5) with tear-off plate or cutter.

4. Lift print roller (4) from its retainers (3).

5. Remove deposits with roller cleaner and a soft cloth, or replace it if the

roller appears damaged.

6. Push roller with bearings (1) into the retainer (3) until they click into place.

7. Fold up cover (5) with tear-off plate or cutter.

7 Maintenance

Questions and Answers:

Need help?

Do you have a question about the CAB EOS and is the answer not in the manual?

CAB EOS Specifications

General

Power Supply	100-240V AC, 50/60 Hz
Print Method	Thermal transfer
Print Width	Up to 105.6 mm (depending on model)
Interfaces	USB, Serial, Ethernet
Display	LCD
Supported Barcodes	Code 39, Code 128, UPC-A, UPC-E, EAN-8, EAN-13, Interleaved 2 of 5, Data Matrix, QR Code
Supported Operating Systems	Windows
Resolution	203 dpi
Media Width	4.33" (110 mm)
