2.1 Device Overview
1
2
3
4
5
6
7
8
1 Cover
2 Margin stops
3 Roll retainer
4 Ribbon supply hub
5 Ribbon take-up hub
6 Roller
7 Print mechanics
8 Touchscreen display
Fig. 1 EOS1 with Tear-off Plate
9
9 Cutter
Fig. 2 EOS1 with Cutter
