3 Control Panel

3.3 Symbols on the Start Display

Symbol Status Function

Ready To ofine menu

Ready Feeds a blank label

Ready After the end of a print job,

print an additional label with the information of the

previous print job.

Printing label Interrupt print job,

printer goes into "Pause" state

Pause Continue the print job,

printer goes into "Printing label" state

Ready Delete internal memory,

the last label can no longer be reprinted.

Printing label

Press shortly g

cancels the current print job

Press long g cancels the current print job

and deletes all print jobs

Pause

Table 1 Symbols on the Start Display

Questions and Answers:

Need help?

Do you have a question about the CAB EOS and is the answer not in the manual?

CAB EOS Specifications

General

Power Supply	100-240V AC, 50/60 Hz
Print Method	Thermal transfer
Print Width	Up to 105.6 mm (depending on model)
Interfaces	USB, Serial, Ethernet
Display	LCD
Supported Barcodes	Code 39, Code 128, UPC-A, UPC-E, EAN-8, EAN-13, Interleaved 2 of 5, Data Matrix, QR Code
Supported Operating Systems	Windows
Resolution	203 dpi
Media Width	4.33" (110 mm)
