CAB MACH1 User Manual

7
2 Device Overview
2.2 Device Views
2.2.1 Front View
1
2
5
8
9
3
4
6 7
1 Printer cover
2 Operation panel
3 Cover of ribbon rewind mechanism
4 Front cover
5 Cover release catches
6 LED Power
7 LED Status
8 FEED Button
9 POWER Button
Fig. 2 Front View
2.2.2 Rear View
5
11
10
12 13 14 15
5 Cover release catches
10 Fan-fold label insert
11 Calibration button
12 Power jack
13 USB Port
14 Serial Port
15 Ethernet Port
Fig. 3 Rear View
