CAB SQUIX Series User Manual

18 18
Parameter Meaning Default
Print on demand Peel-off mode : Behavior after removing a label from the peel position
On: The next label will be printed and peeled-off after touching
Off: The next label will be printed and peeled-off immediately
Off
Cut mode : Behavior between the cuts
On:
After cutting the next label will be printed and cut after touching
Off: All labels will be printed and cut nonstop
Reprint Printing of another label with the information of the previous print job by
touching
.
This function can be executed until the print buffer is cleared with
.
Re-render: Adaption of counter values, variable data can be newly put in.
Duplicate: New label is identical with the last label of the print job.
Off: No reprint
Re-render
Single label buffer Thenextlabelwillbeprocessedonlywhenthecurrentonehasnished
printing.
Off
Length scale Eliminate deviations of the print length from the length set in the
programming
0,0%
Slippage correction To correct the slippage of the media transport the positioning of the print
image will be re-adjusted to the position of the last detected label front
edge considering the programmed label distance.
Off
Table 5 Parameters of the Setup > Printing menu
6.1.2 Labels
 Start menu.
 Select Setup > Labels.
Parameter Meaning Default
Label sensor Method for detecting the starting end of the label.
Gap Sensor: Detection using changes in the transparency between the
label and label gap.
Bottom-Reect
:Detectionusingreexmarksonthebottomofthemedium.
Continuous media: Checking the existence of media only.
Gap sensor
Calibrate label sensor To adapt the printer electronics to the label sensor and
 SQUIX / EOS / HERMES Q / PX Q: the used liner material.
 MACH 4S: the used liner and ribbon material.
Extrapolate labels The positions of the labels which are between the label sensor and the
printheadarecalculatedfromtherstlabelrecognizedbythesensor
and the programmed label distance. That way those labels can be
printed although the printhead previously was open.
Off
Ignore paper end Suppression of wrong Out of paper error messages when using labels with
transparent liner.
Off
Sensor unwinder
 Only at HERMES Q!
On: Sensor for monitoring the label supply roll is activated.
Off: Sensor for monitoring the label supply roll is not activated.
On
6 Conguration

CAB SQUIX Series Specifications

General

Peeler	Optional
Print Technology	Thermal transfer
Connectivity	USB, Ethernet
Display	LCD
Sensors	Label gap sensor
Print Resolution	300 dpi
