CAB SQUIX Series User Manual

45
8 Diagnostic Functions
8.5 Record Data Steam

Access only with external storage device!
The function Record data stream
allowstostoredataincomingviaaninterfaceasan.lblletoanexternalstorage
device (SD card, USB memory module) installed on the printer.
 Insert SD card or USB memory module.
 Start menu.
 Select Diagnostics > Record data stream.
 Select the external storage device.
 Enteralename.
Thepredenednameiscomposedoftheidentier"log",date,clocktimeandthesufx".lbl",butmayalsobe
altered.
Conrmtheselectionwith .
 In the status line of the display the data saving is indicated by the symbol .
 Sendprintjobs.Alldatareceivedbytheprinterarestoredinthe.lblle.
 To complete the function select Diagnostics > Record data streamagainandconrmwithOK.The.lbllewillbestored
in the root of the storage device.
Figure 24 Data stream record

CAB SQUIX Series Specifications

General

Peeler	Optional
Print Technology	Thermal transfer
Connectivity	USB, Ethernet
Display	LCD
Sensors	Label gap sensor
Print Resolution	300 dpi
