CAB SQUIX Series User Manual

36 36
7 Test Functions
7.1 Overview
The Test menu contains test functions providing information on:
• themostimportantcongurationparameters
• the fonts available in the printer
• important hardware components and connected peripheral devices
• the print image quality and state of the thermal printhead
• available Wi-Fi networks.
7.2 Status Print
The Status print
functionprintsatestimagecontaininginformationonthecongurationandstatusoftheprinter.The
printoutoccursusingtheheatlevelandprintspeedspeciedintheSetup > Printing menu.
i
Notice!
The printout occurs without taking the label gaps into consideration. This is why endless media are most
suitable for this purpose.
 Insert printable medium (labels, endless paper) which extends across the entire printing width.
 If the printout is to occur using thermal transfer printing, insert transfer ribbon with the maximum width.
 Start menu.
 Select Test > Status print.
The printout can be canceled with
.
Status print
Wed Aug 14 10:48:21 2019
cab SQUIX 4/300MP
Firmware V5.27 (Jul 25, 2019) - #164162036456
Printing
Heat level 0
Print speed 75 mm/s
Print position X 0,0 mm
Print position Y 0,0 mm
Backfeed smart
Backfeed position 1,0 mm
Print on demand Off
Reprint Re-render
Single label buffer Off
Length scale 0,0 %
Slippage correction Off
Labels
Label sensor Gap
Extrapolate labels Off
Ignore paper end Off
Ribbon
Transfer print On
Warn level ribbon 32 mm
Pause on warning Off
Monitor ink side Off
Tearing-off
Tear-off mode On
Tear-off position 0,0 mm
Cutting
Cut position 0,0 mm
Perforation level 0
Peeling-off
Peel-off position 0,0 mm
Backfeed delay 250 ms
Labelling
Transfer mode Stamp on
Cycle sequence Print-Apply
Waiting position up
Blow time 1000 ms
Roll-on time 1000 ms
Support delay on 0 ms
Support delay off 0 ms
Start delay 0 ms
Lock time 0 ms
Vacuum delay On
Vacuum control On
Label hand-over Passive
Cleaning blow Off
Peel-off position 0,0 mm
Interfaces
Ethernet
Hostname cab-999163
DHCP Off
IP address 192.168.9.13
Netmask 255.255.255.0
Gateway Off
DNS server 0.0.0.0
Wi-Fi
Wi-Fi On
Access Point cabgast
DHCP Off
IP address 172.20.200.93
Netmask 255.255.255.0
Gateway Off
DNS server 0.0.0.0
Network services
FTP On
LPD On
RawIP On
RawIP port 9100
RawIP timeout Default
Website On
Web service On
SNMP On
SNMP community public
VNC server On
Zeroconf On
OPC UA Off
RS-232
Baud rate 115200
Handshake RTS/CTS
I/O
START mode Edge
REPRINT mode Edge
JOBDEL mode Cancel print job
Start delay 0 ms
Lock time 0 ms
Legacy I/O Off
Errors
Error-Reprint On
Syntax error On
Barcode error On
Network error On
Region
Language English
Country Germany
Keyboard Automatic
Time
Date 04.08.2017
Time 08:02:16
Time zone UTC+1 (Berlin,Paris)
Daylight saving EU
Time synchronization NTP
Time server
Display
Orientation 0°
Brightness 8
Time powersave 5 min
Peripheral button On
Reprint button On
Pause button On
Cancel button On
Feed button On
Interpreter
Character set UTF-8
USB JScript
RS-232 JScript
FTP JScript
LPD JScript
RawIP JScript
Bluetooth JScript
ZPL
Print width 100,0 mm
Label length 150,0 mm
Storage
Default storage SD Card
Security
PIN protection On
Security web service Digest
TLS/SSL Off
Block ext. storage Off
Block USB ports Off
Extras
Cleaning interval 1000 m
Service
Printhead zero pos. X 0,0 mm
Printhead zero pos. Y 0,0 mm
Printer Info
Operative time
Total 346h 55min
Service 104h 02min
Number of labels
Total 2457
Service 1060
Thermal transfer
Total 68,084 m
Service 20,154 m
Thermal direct
Total 32,086 m
Service 0,080 m
Temperature 27,4 °C
Heat voltage 24,2 V
Heat level
< 0 14,011 m
0-7 86,092 m
8-14 0,000 m
> 14 0,000 m
Label sensor
Brightness 13-27 / 26-54
Figure 16 Status print
Parameters marked italic are only printed when the printer is equipped with the respective optional
assembly or when the service key is inserted
