CAB SQUIX Series User Manual

40 40
7 Test Functions
7.6 Wi-Fi Status

Access only when a Wi-Fi stick is installed and Wi-Fi is activated!
Not in the Wi-Fi operation mode "Hotspot".
The Wi-Fi status function prints out a list with the most important parameters of the accessible Wireless Access Points.
TheprintoutoccursusingtheheatlevelandprintspeedspeciedintheSetup > Printing menu.
i
Notice!
The printout occurs without taking the label gaps into consideration. This is why endless media are most
suitable for this purpose.
 Insert printable medium (labels, endless paper) which extends across the entire printing width.
 If the printout is to occur using thermal transfer printing, insert transfer ribbon with the maximum width.
 Start menu.
 Select Test > Wi-Fi status.
The printout can be canceled with
.
Wi-Fi status
Wed Aug 14 10:36:15 2019
cab SQUIX 4/300MP
Firmware V5.27 (Jul 25, 2019) - #164162036456
Channel Name/BSS ID Signal level Security
1 default
●●●●●
WPA2-PSK
00:24:b2:36:98:60
1 cab-firma
●●●●●
WPA2-PSK
00:24:b2:36:98:61
1 cab-gast
●●●●●
WPA2-PSK
00:24:b2:36:98:62
11 default
●○○○○
WPA2-PSK
00:24:b2:36:98:60
11 cab-firma
●○○○○
WPA2-PSK
00:24:b2:36:98:61
11 cab-gast
○○○○○
WPA2-PSK
00:24:b2:36:98:62
Figure 20 Wi-Fi status
The parameters have the following meaning :
Column Meaning
Channel Channel; frequency range of the Access Point
Name/BSS ID
Name of the wireless LAN
MAC address of the Access Points
Signal level Scale of the Wi-Fi signal strength
Security Type of data encryption
Table 23 Parameters of the WiFi status
