Fuse
IGN
1”
BATT
1
BRAKES
Usage
Front and Rear Ignition-
1
Relay,
Oxygen Sensor
1
and
2
Fuse, Fuel
Fuse, Cruise Fuse,
DFU
Relay, Front
and Rear Fog Lamp Relay, Control
Power Back-up Relay, Ignition-
1
Fuse,
Fuel Pump Relay
Starter Relay and Solenoid, ParldXev
Fuse, Park Relay, PCM Fuse, AC
Compressor Fuse and Relay,
Fan
Relays, Reverse Relay
ABS
Brake Modulator
COOL
FNS
Cooling Fan Relays
1
and
3
*
Do
not alter
OBD
I1
related fuses or circuit breakers.
Fuses
and
Circuit
Breakers
The wiring circuits in your vehicle are protected from
short circuits by a combination
of
fuses and circuit
breakers.
This
greatly reduces the chance of fires
caused by electrical problems.
Look at the silver-colored band inside the fuse. If the
band is broken or melted, replace the fuse. Be sure you
replace a bad fuse with
a
new one of the identical size
and rating.
If
you ever have a problem on the road and don’t have
a spare fuse, you can “borrow” one that has the same
amperage. Pick some feature of your vehicle that
you can get along without
--
like the radio
or
cigarette lighter
--
and use its
fuse,
if
it is the correct
amperage. Replace it as soon as you can.
There
are
two fuse blocks
in
your vehicle:
the
engine
compartment fuse block and the rear compartment
fuse block.
