CAME FAST 70 User Manual

p.
17
17 - Manual code:
FA00095-EN
FA00095-EN v.
4 - 08/2017 - © Came S.p.A. The contents of this manual may be changed at any time without prior notice.
Functions map
F 1 Total stop function (1-2)
F 2 Function associated to input 2-CX
F 3 Function associated to input 2-CY
F 5 Safety test function
F 6 Maintained action function
F 7 Control mode on 2-7
F 8 Control mode on 2-3P
F 9 Obstruction detection with motor idle function
F 10 Function associated to the open gate signal or electric lock enabling.
F 11 Encoder exclusion
F 12 Slowed-down start function
F 13 Closing thrust function
F 14 Sensor type selection function
F 16 Ram jolt function
F 18 Additional light function
F 19 Automatic closing time
F 20 Automatic closing time after partial opening
F 21 Prefl ashing time
F 22 Working time
F 23 Delayed opening time
F 24 Delayed closing time
F 26 Ram jolt time
F 27 Lock time
F 28 Adjusting opening speed
F 30 Adjusting opening slow-down speed
F 33 Adjusting calibration speed
F 34 Sensitivity during movement
F 35 Sensitivity during slow-down
F 36 Adjusting partial opening
F 37 Adjusting the M1 gearmotor's opening slow-down start point
F 38 Adjusting the M1 gearmotor's closing slow-down start point
F 39 Adjusting the M1 gearmotor's opening approach starting point
F 40 Adjusting the M1 gearmotor's closing approach starting point
F 41 Adjusting the M2 gearmotor's opening slow-down starting point
F 42 Adjusting the M2 gearmotor's closing slow-down starting point
F 43 Adjusting the M2 gearmotor's opening approach starting point
F 44 Adjusting the M2 gearmotor's closing approach starting point
F 46 Setting the motor numbers
F 49 Managing the serial connection
F 50 Saving data in memory roll
F 51 Reading memory roll data
F 56 Peripheral number
F 63 Changing COM speed
F 65 Function associated to the RIO-EDGE [T1] input
F 66 Function associated to the RIO-EDGE [T2] input
F 67 Function associated to the RIO-CELL [T1] input
F 68 Function associated to the RIO-CELL [T2] input
U 1 Entering new user with an associated command
U 2 Deleting single users
U 3 Deleting all users
A 1 Motor type
A 2 Motor test
A 3 Travel calibration
A 4 Resetting parameters
A 5 Counting maneuvers
H 1 Software version

CAME FAST 70 Specifications

General

Power Supply	230 V AC
Motor Power	300 W
Motor Voltage	230 V AC
Current	1.3 A
Thrust	3000 N
Intermittence	30%
Operating Temperature	-20°C to +55°C
Protection Rating	IP44
Opening Speed	Adjustable
Closing Speed	Adjustable
Safety Features	Obstacle detection
Type	Electromechanical
