p.
18 - Manual code:
FA00095-EN v.
4 - 08/2017 - © Came S.p.A. The contents of this manual may be changed at any time without prior notice.
Functions menu
IMPORTANT! Start programming by fi rst performing functions MOTOR TYPE (A1), NUMBER OF MOTORS (F46), MOTORS TEST (A2) and
TRAVEL CALIBRATION (A3).
⚠
Programming the features is to be done when the operator is stopped.
You can memorize up to 25 users.
F 1 Total stop [1-2] 0 = Deactivated (default) / 1 = Activated
NC input – Gate stop that excludes any automatic closing; to resume movement, use the control device. The safety device is inserted into [1-2].
F 2 Input [2-CX] 0 = Deactivated (default) / 1 = C1 / 2 = C2 / 3 = C3 / 4 = C4 / 7 = C7 / 8 = C8
NC input – Can associate: C1 = reopening during closing by photocells, C2 = reclosing during opening by photocells, C3 = partial stop, C4 =
obstruction wait, C7 = reopening during closing by sensitive safety-edges, C8 = reclosing during opening by sensitive safety-edges.
The C3 Partial stop function only appears if the F 19 Automatic closing time function is activated.
F 3 Input [2-CY] 0 = Deactivated (default) / 1 = C1 / 2 = C2 / 3 = C3 / 4 = C4 / 7 = C7 / 8 = C8
NC input – Can associate: C1 = reopening during closing by photocells, C2 = reclosing during opening by photocells, C3 = partial stop, C4 =
obstruction wait, C7 = reopening during closing by sensitive safety-edges, C8 = reclosing during opening by sensitive safety-edges.
The C3 Partial stop function only appears if the F 19 Automatic closing time function is activated.
F 5 Safety test 0 = Deactivated (default) / 1 = CX / 2 = CY / 4 = CX+CY
After every opening or closing command, the board will check whether the photocells are working properly.
The safety test is always active for wireless devices.
F 6 Maintained action 0 = Deactivated (default) / 1 = Activated
The gate opens and closes by keeping the button pressed. Opening button on contact 2-3P and closing button on contact 2-7. All other control
devices, even radio-based ones, are excluded.
F 7 Command [2-7] 0 = Step-step (default) / 1 = Sequential
From the control device connected to 2-7 it performs the step-step (open-close-invert) or sequential (open-stop-close-stop) command.
F 8 Command [2-3P] 0 = Pedestrian opening (default) / 1 = Partial opening
From the control device connected to 2-3P, it performs the pedestrian opening (completely opened M2 leaf) or the partial opening ( partially
opened 2 leaf): the degree of opening depends on the travel percentage adjustment set with F 36).
F 9 Obstruction detection
when motor is idle
0 = Deactivated (default) / 1 = Activated
With the gate closed, opened or totally stopped, the gearmotor stays idle if the safety devices, that is, photocells or sensitive safety-edges detect
an obstruction.
F 10 Open-gate signal or
electric lock enabling
0 = lit when gate is open or moving (default) /
1 = when opening it fl ashes intermittently every half-second,
when closing it fl ashes intermittently every second,
stays lit when gate is open
stays o when gate is closed /
2 = enabled electric lock.
It signals the gate status. The signaling device is connected to 10-5 or, alternatively, it enables the electric lock connected to transformer's 17
V-output and to terminal 5.
In the latter case, connect a 3.15 A fuse.
F 11 Encoder 0 = Activated (default) / 1 = Deactivated
Managing slow-downs, obstruction detections and sensitivity.
F 12 Slowed-down start 0 = Deactivated (default) / 1 = Activated
With each opening and closing command, the gate starts moving slowly for a few seconds.
F 13 Closing thrust 0 = deactivated (default) / 1 = minimum thrust / 2 = medium thrust / 3 = maximum thrust
At the closing limit switch, the gearmotors make the leaves perform a brief closing thrust.
F 14 Select sensor type 0 = transponder sensor or magnetic card reader command
1 = command with keypad selector (default)
Setting the type of sensor for controlling the operator.
F 16 Ramming jolt 0 = Deactivated (default) / 1 = Activated
Before every opening or closing maneuver, the leaves thrust inwards to release the electric lock. The thrust time, is set with F 26.
F 18 Extra light 0 = Flashing (default) / 1 = Cycle
Output on contact 10-E.
Flashing light: it fl ashes during the gate's opening and closing phases.
Cycle: it stays lit from the beginning of the opening until complete closing, including the waiting time before the automatic closing.
F 19 Automatic closing time 0 = Deactivated (default) / 1 = 1 second /… / 180 = 180 seconds
