The automatic-closing wait starts when the opening limit switch point is reached and can be set to between 1 and 180 seconds. The automatic
closing does not turn on if any of the safety devices trigger when an obstruction is detected, after a total stop or during a power outage.
F 20 Automatic closing time
after partial opening
0 = Deactivated (default) / 1 = 1 second /… / 180 = 180 seconds
The wait before the automatic closing starts after a partial opening command for an adjustable time of between 1 s and 180 s.
The automatic closing does not turn on if any of the safety devices trigger when an obstruction is detected, after a total stop or during a power
outage.
F 21 Prefl ashing time 0 = Deactivated (default) / 1 = 1 second /… / 10 = 10 seconds
Adjusting the pre-fl ashing time for the fl ashing light connected to 10-E before each maneuver. The fl ashing time is adjustable from one to ten
seconds.
F 22 Working time 5 = 5 seconds /… / 120 = 120 seconds (default) /… / 180 = 180 seconds.
Motors working time, when opening and closing. Adjustable between fi ve and 180 seconds.
F 23 Delayed opening time 0 = 0 seconds /… / 2 = 2 seconds (default) /… / 10 = 10 seconds.
After an opening command, the M1 gearmotor starts delayed. The delay time is adjustable between one and two seconds.
F 24 Delayed closing time 0 = 0 seconds/… / 5 = 5 seconds (default) /… / 25 = 25 seconds.
After either a closing command or an automatic closing, the M2 gearmotor starts delayed. The delay time is adjustable between one and fi ve
seconds.
F 26 Ram jolt time 1 = 1 second (default) / 2 = 2 seconds
After an opening or closing command, the gearmotor thrusts inward for an adjustable time between one and two seconds.
F 27 Lock time 1 = 1 second (default) / 4 = 4 seconds
After an opening or closing command, the electric lock releases for an adjustable time between one and four seconds.
F 28 Travel speed 60 = Minimum speed /… / 100 = Maximum speeddefault)
Setting the gate's opening and closing speeds, calculated as a percentage.
 For FA7024CB gearmotors, the minimum speed is 50.
F 30 Slow-down speed 10 = Minimum speed /… / 50 = Speed (default) /... / 60 = Maximum speed
Setting the gate's opening and closing slow-down speed, calculated as a percentage.
 For FA7024CB gearmotors, the minimum speed is 30.
F 33 Calibration speed 20 = Minimum speed /… / 50 = Speed (default) /... / 60 = Maximum speed
Setting the gearmotors' speeds during calibration, calculated as a percentage.
F 34 Travel sensitivity 10 = sensitivity /… / 100 = minimum sensitivity (default)
Adjusting obstruction detection sensitivity during boom travel.
F 35 Slow-down speed 10 = sensitivity /… / 100 = minimum sensitivity (default)
Adjusting the obstruction-detection sensitivity during slow-downs
F 36 Adjusting partial opening 10 = 10% of the travel /… / 40 = 40% of the travel (default) /... / 80 = 80% of the travel
Adjustment as a percentage of total travel, during gate opening.
F 37 M1 slow-down starting
point
10 = 10% of the travel /… / 25 = 25% of the travel (default) /… / 70 = 70% of the travel
Adjusting as a percentage of the total travel, the opening slow-down starting point of motor M1.
 This function only appears if the Encoder function is activated.
F 38 M1 closing slow-down
point
10 = 10% of the travel /… / 25 = 25% of the travel (default) /… / 60 = 60% of the travel
Adjusting as a percentage of the total travel, the closing slow-down starting point of motor M1.
 This function only appears if the Encoder function is activated.
F 39 M1 opening approach
point
1 = 1% of the travel /… / 10 = 10% of the travel (default)
Adjusting as a percentage of the total travel, the M1 motor's opening approach starting point.
 This function only appears if the Encoder function is activated.
F 40 M1 closing approach point 1 = 1% of the travel /… / 10 = 10% of the travel (default)
Adjusting as a percentage of the total travel, the M1 motor's closing-approach starting point.
 This function only appears if the Encoder function is activated.

CAME FAST 70 Specifications

General

Power Supply	230 V AC
Motor Power	300 W
Motor Voltage	230 V AC
Current	1.3 A
Thrust	3000 N
Intermittence	30%
Operating Temperature	-20°C to +55°C
Protection Rating	IP44
Opening Speed	Adjustable
Closing Speed	Adjustable
Safety Features	Obstacle detection
Type	Electromechanical
