CAME ZE5 User Manual

#!-%
MM
MM
MM
Pag.
3
3 - Manual code:
319T92
319T92 ver.
2.0
2.0 11/2012 © CAME cancelli automatici s.p.a.
The data and information reported in this installation manual are susceptible to change at any time and without obligation to notify users.
EN
Technical data
Dimensions
FUSE TABLE
to protect: fuses for:
Electronic board (line)
5 A
Command devices 630 mA
Accessories 1.6 A
TECHNICAL DATA
Power supply 230 V - 50/60 Hz
Maximum allowed power load 400 W
Power draw when idle 150 mA
Maximum power rating for 24V
accessories
40 W
Circuit insulation class
Container material ABS
Degree of protection IP54
Working temperature -20 / +55 °C

CAME ZE5 Specifications

General

Brand	CAME
Model	ZE5
Category	Control Panel
Language	English
