A message will appear informing you that analysis is in
progress.
The Layout menu will appear automatically.
Important
• If the range selected in Excel 2007/2010 is too large, it will not be possible to analyze the data. Select a smaller
range and then run the analysis.
Note
• If data analysis requires time, a message dialog will appear. If you select No, you will return to the application.
5 Select Roll Paper Width that is set in the printer.
6 Select image size.
7 Select layout.
8 To configure Binding, click the Binding Settings button.
Refer to Configuring Binding (Excel) →P.290 for details on the procedure for configuring Binding.
iPF760 Print Selected Area (Excel)
User's Guide
Windows Software Print Plug-In for Office
289

Canon imagePROGRAF iPF760 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.8 mm
Maximum print size	-
Maximum roll length	18 m
Media width (rolls)	254 - 914.4 mm
Media width (sheets)	203.2 - 917 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1, A2, A3
ISO B-series sizes (B0...B9)	B1, B2, B4
Certification	CE, RoHS, ECO, WEEE
Sound power level (standby)	35 dB
Sound pressure level (printing)	50 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet interface type	Gigabit Ethernet
Sustainability certificates	ENERGY STAR
Power requirements	100 - 240V, 50/60Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7\\r Mac OS 10.5 - 10.7.x

Weight and Dimensions

Dimensions (WxDxH)	1304 x 1100 x 1062 mm
