Canon imagePROGRAF iPF760 User Manual

When specifying an IPv6 IP address
1
Start imagePROGRAF Device Setup Utility from the
start menu.
2 In the Device Name list displayed, select the printer to configure.
3 Choose Protocol Settings from the Printer menu.
4
Select the IPv6 tab.
5 In IPv6, select On.
6 When there is an IPv6-compatible router in the network environment, select On in Stateless Address.
Additionally, when there is an DHCPv6-compatible server in the network environment, select On in DHCPv6.
Note
• When there is no IPv6-compatible router or DHCPv6-compatible server, select On in Manual and enter the IPv6
Address and Prefix Length.
7 Click Set.
8 Click OK after the Confirmation message is displayed.
9 Exit imagePROGRAF Device Setup Utility.
Configuring the IP Address Using imagePROGRAF Device Setup Utility
iPF760
User's Guide
Windows Software Device Setup Utility
308

Canon imagePROGRAF iPF760 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.8 mm
Maximum print size	-
Maximum roll length	18 m
Media width (rolls)	254 - 914.4 mm
Media width (sheets)	203.2 - 917 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1, A2, A3
ISO B-series sizes (B0...B9)	B1, B2, B4
Certification	CE, RoHS, ECO, WEEE
Sound power level (standby)	35 dB
Sound pressure level (printing)	50 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet interface type	Gigabit Ethernet
Sustainability certificates	ENERGY STAR
Power requirements	100 - 240V, 50/60Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7\\r Mac OS 10.5 - 10.7.x

Weight and Dimensions

Dimensions (WxDxH)	1304 x 1100 x 1062 mm
