Canon imagePROGRAF iPF760 User Manual

ICC Matching Mode
The following options are available when you select ICC Matching Mode, in the A Matching Mode list.
Note
• To display the Matching pane, on the Main pane, click Color Settings by Color Mode in Advanced Settings, and then click
the Matching tab.(See "Main Pane →P.330 ")
• A Matching Mode
Select the color matching mode to use, as desired.
• B Input Profile Settings
You can choose Input Profile.
Various options are available depending on your selected A Matching Mode.
• C Matching Method
You can choose C Matching Method.
Various options are available depending on your selected A Matching Mode.
• D Printer Profile Settings
Specify the printer profile as desired.
Note
• For details on settings items, see "Adjusting the Color in the Printer Driver →P.56 "
Matching pane iPF760
User's Guide
Mac OS X Software Printer Driver
336

Canon imagePROGRAF iPF760 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.8 mm
Maximum print size	-
Maximum roll length	18 m
Media width (rolls)	254 - 914.4 mm
Media width (sheets)	203.2 - 917 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1, A2, A3
ISO B-series sizes (B0...B9)	B1, B2, B4
Certification	CE, RoHS, ECO, WEEE
Sound power level (standby)	35 dB
Sound pressure level (printing)	50 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet interface type	Gigabit Ethernet
Sustainability certificates	ENERGY STAR
Power requirements	100 - 240V, 50/60Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7\\r Mac OS 10.5 - 10.7.x

Weight and Dimensions

Dimensions (WxDxH)	1304 x 1100 x 1062 mm
