Canon imagePROGRAF TM-340 Online Manual

Note
• It may take a while for the printer and network device to become ready for use once they are•
turned on again. After turning it on, wait for a while and proceed.
2.
Check PC network connection
2.
Can you view any web pages on your computer? Make sure the computer and network device (router,
etc.) are configured and the computer is connected to the network.
If you cannot view web pages, unplug the cable connected to the router's WAN side. Connect the
cable directly to the computer to see if you can view web pages on the Internet.
Check the settings for the router if you were able to view web pages. For details on checking
the settings of the router, refer to the instruction manual supplied with the router or contact the
manufacturer. Refer also to the instruction manual regarding the connection of the provider.
Once you complete checking the router, configure the network settings of your computer. For the
procedures, refer to the instruction manual supplied with the computer, or contact the manufacturer.
Once you complete setting up the router and your computer, configure the settings on your computer
to view web pages, using the information of the router.
Proceed once you can view web pages on your computer.
3. Check printer's wired LAN settings3.
Make sure the icon is displayed on the touch screen.
If icon is not displayed:
The printer is not set to enable wired communication. Change the printer settings in order to use wired
LAN.
When you complete checking [Step 1] above, try to set up from the beginning.
If the printer cannot be detected after trying to set up from the beginning, proceed to [Step 2].
Step 2
Solve the Problem, Using Wi-Fi Connection Assistant
Diagnose and repair the network connections using Wi-Fi Connection Assistant.
Download Wi-Fi Connection Assistant from the below page, and install it on your computer.
Checking Printer Connection Status Using Wi-Fi Connection Assistant
681

Canon imagePROGRAF TM-340 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	-
Page description languages	CALS G4, HP-GL/2, HP-RTL, PDF 1.7
Media thickness	0.07 - 0.8 mm
Maximum print size	A0 (841 x 1189 mm)
Maximum roll width	917 mm
Maximum roll length	18 m
Maximum roll diameter	150 mm
Paper tray media types	Plain paper, Roll
ISO A-series sizes (A0...A9)	A0, A1, A2, A3, A3+
USB connector	USB Type-B
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint
Control type	Touch
Product color	Black, White
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Power consumption (off)	0.1 W
Power consumption (sleep)	2.2 W
Power consumption (typical)	65 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Mac operating systems supported	Mac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.7.5 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura
Windows operating systems supported	Windows 10, Windows 7, Windows 8.1
Package depth	912 mm
Package width	1462 mm
Package height	801 mm
Package weight	100000 g
Maximum scan resolution	600 x 600 DPI

Weight and Dimensions

Depth	868 mm
Width	1285 mm
Height	1060 mm
