Chapter 5
5-30
the test.
b-3) Operation key test
Press the Start key to select the Operation key test after the LED lamp test is complete.
In this test, you press the key corresponding to the displayed character to put it out. The table giving the
correspondence between the characters and the keys is shown below.
T-5-4
Character Operation key Character Operation key
O ON/OFF key C COPY key
F FAX key S SCAN key
P PHOTO PRINT key M Additional Function key
U Menu key H Photo Index Key
- key + Key
T Directory E Set
R Redial/Pause N Black key
L Color key
