Chapter 6
6-1
6.1 Main Body
6.1.1 Installation
0002-0817
Reference:
This machine is to be installed by a user, so this service manual contains only a briefing of installation procedures.
Please refer to the Set-up Sheet enclosed in the package of the machine for more details.
* Check an installation space.
* Unpack the machine, and check the attachments
Make sure none is missing and there is no damage.
* Remove the package material
Remove all tape and protective material used on the machine.
* Connect the cable
Connect the telephone line and any necessary external device.
* Turn on the power
Connect the power cord. If the machine is not turn on, press [ON/OFF] to turn on the machine.
* Load paper
Place a stack of paper in the multi-purpose tray.
* Install the printhead
Remove the protective cap, and then install the printhead into the holder.
* Install the ink tanks
Pull the tape and remove the protective cap, and then install the ink tanks. After install, align the printhead.
* Install the software
Install the software in the computer.
* Connect the USB cable
Connect the USB cable to complete the computer settings.
* Setting for facsimile (for MP390)
Register the date and time, unit telephone number, and unit name.
6.1.2 Checking Operation
0002-0824
* Check the level of quality for both reading and printing.
Make a copy, and see if it is free of a fault for both reading and printing.
* Conduct a communications test. (For MP390)
Send and receive a fax by connecting to another fax machine, making sure that the image is
normally sent and the received image is normally printed.
