Chapter 4
4-18
F-4-10
A: Printer ROM version
B: MAIN-ROM-version
c) Reports output automatically
Memory clear report
The machine automatically outputs a memory clear report when the power is turned on after a power cut.
F-4-11
TX/RX NO : Indicates four digits of the transaction number
MODE : Indicates, TRANSMIT, MEMORY RX etc.
CONNECTION TEL/ID : Number sent from the other party or number dialled
PGS. : Number of pages are stored in memory
SET TIME : Time when data is stored in memory
WLD-XX-XX /X.XX
A
B
