5314M-0608-020E
5314M-0602-080E
1. Confirm that the grass outlet cover closes.
2. Start the engine and shift the accelerator lever to the
intermediate position between "HIGH" and "LOW".
* When the rotary cutter is in highest position,
the cutting blade clutch cannot be shifted “ON”.
Slightly lower rotary cutter before shifting blade
clutch.
3. Push the blade clutch lever slowly to “ON”.
5314M-0608-030E
To Next Page
