• When adjusting seat, make certain the seat is securely locked.
Adjusting Seat
1. Pull up lock lever to turn seat.
3670M-0401-040E
Lock Lever
Turning seat
1. Pull slide lever to slide seat to a desired
position.
2. Pull seat back adjuster to adjust seat back to
the desired position.
3. Pull firmness adjuster lever to adjust the
seat firmness to suit operator's weight and
preference. Pull firmness adjuster lever fuilly
to undo it.
Slide Lever
Seat Back Adjuster
Firmness Adjuster
3670M-0401-050E
Adjusting seat
• Fuel : Diesel Fuel.
• Fuel Tank Capacity : 45L
NOTE
3670M-0401-030E
Fuel Filler Cap
2. Open fuel filler cap.
3. Insert key in main switch and turn it to
[ | (On)] position.
4. Fill fuel. Check fuel gauge when filling.
5. Turn main switch to [ (Off)] position and
remove key.
6. Put fuel filler cap back and tighten it securely.
7. Close engine hood.
• When seat is turned, the direction that seat
is facing is FORWARD for the operation of
steering levers.
NOTE
