CanyCom S25A - Using Safety Prop

Operation
-32-
4
Using Safety Prop
• Place safety prop under bucket when inspecting or working under bucket.
• Make certain to undo safety prop before lowering bucket.
1. Raise bucket.
2. Hold the bucket with safety prop.
3670M-0403-050E
Safety Prop
12. When bucket reaches its limit, a hissing
noise is heard; move turn lever back to
[ (neutral)] position.
13. Turn lock plate back in place to lock turn
lever.
3670M-0403-040E
Clockwise Turn
Counter-
clockwise Turn
