1. Move the throttle lever to [ (fast)] position
to increase the engine speed.
Dumping
2. Turn the lock plate to the side so that the
dump lever can be operated.
3. M o v e d u m p l e v e r g r a d u a l l y t o w a r d
[ (up)] to raise bucket.
4. When bucket reaches its upper limit, a
hissing noise is heard; move dump lever
back to [ (neutral)] position.
5. M o v e d u m p l e v e r g r a d u a l l y t o w a r d
[ (down)] to lower bucket.
6. When bucket reaches its lower limit, a
hissing noise is heard; move dump lever
back to [ (neutral)] position.
7. Turn lock plate back in place to lock dump
lever.
Dumping and Turning Bucket
8. Turn lock plate to the side so that turn lever
can be operated.
9. M o v e t u r n l e v e r g r a d u a l l y t o w a r d
[ (left)] to turn bucket left.
10. When bucket reaches its limit, a hissing
noise is heard; move turn lever back to
[ (neutral)] position.
11. M o v e t u r n l e v e r g r a d u a l l y t o w a r d
[ (right)] to turn bucket right.
