• Oil to Use: Gear Oil, API rating GL-4, SAE
index 90.
NOTE
Travel Motor Oil
• Always park machine on a level surface and block tracks with chocks when
working under machine.
1. Park the machine on a level ground.
2. Drive machine so that filler/drain port of
travel moror is at the bottom.
3. Remove drain plug to drain oil.
4. Reinstall drain plug.
5. Drive machine so that filler/drain port is at
the top of the travel motor.
6. Remove drain check plugs.
7. Fill lubricant into filler port until oil comes out
of check port.
8. Reinstall drain and check plugs.
