2. Make sure dump and turn (Turn & Dump
model) levers are in the neutral position and
lock plate is in the locked position (around
the base of the levers).
3670M-0402-020E
Dump Lever
Lock Plate
3. Make sure steering levers are in the neutral
position.
3670M-0402-030E
Steering Levers
4. Insert key into main switch.
5. Turn main switch to [ (preheat)] position.
3670M-0402-040E
Main Switch
OFF
Preheat
7. Turn main switch to [ (start)] position to
start the engine. Once the engine starts,
release key immediately; sw it ch will
automatically return to [ | (on)] position.
3670M-0402-050E
Main Switch
OFF
ON
Start
• Preheat engine for about 10 seconds when
starting in normal temperature and for
about 20 to 30 seconds when starting in
cold weather (ambient temperature below -5
°C).
• There is no need to preheat if the engine is
already warm.
NOTE
To Next Page
