System Setup
Line Title
Line
Number
Description
Action
Forward/Reverse Detection Press ENTER to change.16
For individual nozzle control to correctly perform, the system must know if the sprayer
is moving in forward or reverse. When the forward/reverse detection is set to OFF=Fwd
Rev Switch, the system is looking for a 12V (reverse beeper) input to tell it the sprayer is
reversing. If the system does not see the 12V signal, it assumes the sprayer is traveling in
the forward direction. If this setting is changed to Compass w/Turn, then a 3-D compass
is used to detect forward/reverse, and the compass calibration is required. For operators
who do not spray in reverse, the best option is to leave this setting at OFF=Fwd Rev
Switch.
Look Ahead Time Press ENTER to change.17
The look ahead time is based on the fastest field speed. The value is an indicator of how
much time the GPS and the system take to react to coverage inputs. If the shutoff is too
early, decrease the value. If the shutoff is too late, increase the value. Set the look ahead
time value at the fastest travel speed expected.
Note: When setting the overlap distance, set the Look Ahead Time value to 0.
Zero Rate Shutoff Press ENTER to change.18
When set to Shutoff the low pressure shutoff is enabled. To disable the low pressure
shutoff, set to Minimum PWM%. When set to shutoff, the system will allow the duty cycle
to drive to 0% or off. This is useful when applying VRT grids with a 0 application rate. The
recommended setting is Minimum PWM%, where it will only allow the system to go to the
low limit nozzle PWM set on the Nozzle PWM Minimum line.
Pressure Control Hold Press ENTER to change.19
Synchro
™
mode operation pressure control hold must be set to Disable or 0.
Pressure Sensor 1 Min. Voltage Press ENTER to change.20
Used to set up pressure sensor 1, which is the PinPoint
™
II spray pressure sensor.
Pressure Sensor 1 Max. Voltage Press ENTER to change.21
Used to set up pressure sensor 1, which is the PinPoint
™
II spray pressure sensor.
Pressure Sensor 1 Min. Pressure Press ENTER to change.22
Used to set up pressure sensor 1, which is the PinPoint
™
II spray pressure sensor.
Pressure Sensor 1 Max. Pressure Press ENTER to change.23
Used to set up pressure sensor 1, which is the PinPoint
™
II spray pressure sensor.
Pressure Sensor 1 Offset Press ENTER to change.24
It is common to have 1 to 5 VDC sensors and 0.5 to 5 VDC sensors. The PSI sensor offset
is used when the sensor does not match a gauge. Entering an offset value will scale the
sensor up or down. The sensor offset allowable range is ±1-9.
©
2020 Capstan Ag Systems, Inc. 47 PinPoint
™
