IMPORTANT:
VERTICAL SUPPORTS REFERED TO IN THIS MANUAL ARE REQUIRED. SUPPORTS
BY OTHERS MUST BE APPROVED BY THE MANUFACTURER AND AUTHORITY HAVING
JURISDICTION (AHJ), GREASE DUCT ONLY. CHIMNEY SYSTEMS MUST USE THE SUPPORTS
LISTED IN THE MANUAL, SUPPORTS BY OTHER ARE NOT ALLOWED. SUPPORT SPACING MUST
BE AS STATED IN THIS MANUAL.
Figure 16 - Vertical Wall Support Kit
1. 5/16” Whiz Nuts and Bolts
2. Wall Support Plate (Top)
3. Flat Support Plates
4. 5/16”-18 x 1-1/2” Self Drilling Screws. Used to
secure double wall duct shell.
5. Side Support Plates
6. Wall Support Plate (Bottom)
7. Wall Plate Support (Middle) - Used for
addition support on 30”/36” Duct
