48
Figure 36 - Chimney Installation Guide Details View 3
1. Base Cap
2. 2” Clearance Plates Installed
3. Combustible Surface
4. Support Fastener Band
5. Shell
6. Double V-band
7. Vertical Support
8. Horizontal Support
9. 1/2” Threaded Rod (Minimum)
A. Vertical Support Spacing, refer to Table 6
B. Horizontal Support Spacing, refer to Table 5
A
A
1
2
4
5
6
7
B
8
3
3
2
9
