Cardinal 225D SmartCell - Page 26

8200-0753-0M Rev A  225D Weight Digital Indicator
20
LOAD CELL ID 8F07E8F HAS NO ADDRESS
Probable Cause
Items to Check
A load cell is responding, but
it is not addressed in the
system.
Go to the addressing menu and assign the load cell ID to
an address.
LOAD CELL ADDRESS X NOT ASSIGNED TO SCALE
Probable Cause
Items to Check
A load cell has not been
assigned to a scale.
Go to addressing menu and assign a scale to the load
cell.
LOW VOLTAGE DETECTED ON LOAD CELL X, Y, Z
Probable Cause
Items to Check
Low power on a load cell.
Load cells at the end of the
CAN daisy chain are most
susceptible to low voltage
errors because of voltage
drop along the cable.
 Too many load cells on the chain.
 Check that cable is connected correctly.
 Check cable for damage.
 Verify that connector is clear of debris.
 Check 225D indicator power supply.
NO WEIGHT
LOAD CELL ID 8F07E8F HAS NO ADDRESS
ID COUNT
lb
G







-------
NO WEIGHT
LOAD CELL ADDRESS 1 NOT ASSIGNED
TO SCALE
ID COUNT
lb
G



-------
NO WEIGHT
LOW VOLTAGE ON LOAD CELL 2,4,6
ID COUNT
lb
G







-------
