8200-0753-0M Rev A  225D Weight Digital Indicator
19
LOAD CELL X HAS BEEN REPLACED
Probable Cause
Items to Check
A load cell has been replaced.
Replaced load cells are automatically detected as long as
only one load cell was replaced. Once a load cell has
been replaced, the 225D will auto detect the new load
cell, display the message that the scale is not Legal-For-
Trade, and will need to be calibrated.
MORE LOAD CELLS THAN EXPECTED
Probable Cause
Items to Check
There are more load cells
than expected connected to
the 225D. For example, the
indicator number of load cells
is set to 8 but the controller
detects there are actually 12
load cells.
Confirm and configure the number of load cells the scale
should have.
NO WEIGHT
LOAD CELL 2 HAS BEEN REPLACED.
SCALE NOT LEGAL FOR TRADE UNTIL
CALIBRATED.
PRESS ENTER TO CONTINUE
lb
G



-------
NO WEIGHT
MORE LOAD CELLS THAN EXPECTED
ID COUNT
lb
G

0








-------
