8527-0544-2M Rev G  APS Enterprise Scale 12

SETUP AND CONFIGURATION, CONT.

PORt1 (RS-232 Serial Port 1)

This is the output format for the first serial port. It should default to “SnnA” in order to be

used with the Enterprise display.

The serial port parameters for this port are fixed at 9600 baud, 8 data bits, 1 stop bit and

No parity.

Press the UNITS key to show current setting. If value displayed is acceptable, press the

UNITS key again to save it. Otherwise, press the ZERO key to step through selections for

a new value and then press the UNITS key to save it.

Options for PORT1 output format are as follows:

SnnA

This selection allows the port to respond to the following commands and

will output Weight on Demand in the appropriate format.

Cardinal ENQ (hex 05)

Detecto AS-410D ~ (tilde, hex 7E), Pounds ONLY Mode

SMA (W)

nci

NCI output format

nntps

Mettler Toledo PS output format

nntsi

Mettler Toledo SICS output format

LPL

Lone Peak Labeling

IMPORTANT! Selecting LPL (Lone Peak Labeling) for the port output

format will change the behavior of the scale. When the scale settles on

“any” positive weight above zero, the display will lock on that weight until

the scale returns to zero.

PORt2 (RS-232 Serial Port 2)

This is the second serial port output format selection. It is identical to PORT1. The serial

port parameters for this port are fixed at 9600 baud, 8 data bits, 1 stop bit and No parity.
