8527-0544-2M Rev G APS Enterprise Scale 26
PARTS IDENTIFICATION, CONT.
SCALE DISPLAY and APSRD (REMOTE DISPLAY)
ITEM PART NO. QTY DESCRIPTION
1 5930-0146-08 1 CAPACITY LABEL
2 6021-2078 4 SCW PAN-HEAD PHILLIPS #1-32X3/8” THD FORM, SS
3 8527-0515-08 1 APS KEYPAD
4 8527-C502-0A 1 PCB ASSY APS10 DISPLAY
5 8527-C502-1A 1 PCB ASSY APS15/160 DISPLAY
6 8527-C502-2A 1 PCB ASSY APS30/70/150 DISPLAY
7 8527-C502-3A 1 PCB ASSY APS250 DISPLAY
8 8527-C502-4A 1 PCB ASSY APSRD DISPLAY
9 8527-D506-08 1 ENCLOSURE FRONT
10 8527-D507-08 1 ENCLOSURE BACK
11 8527-D508-08 1 ENCLOSURE MOUNT
DISPLAY EXTENSION CABLE
ITEM PART NO. QTY DESCRIPTION
6600-2007 1 CABLE 7FT APS DISPLAY EXTENSION
Not Shown
