8527-0544-2M Rev G APS Enterprise Scale 19
PARTS IDENTIFICATION, CONT.
(ALL MODEL EXCEPT APS250)
ITEM PART NO. QTY DESCRIPTION
1 1960-B465-08 2 SPACER FOR EB-XXX-XXXX
3 6013-0077 4 HEX NUT
10 6540-1165 4 LEVELLING FOOT, 1.63 BASE X 3/8”-16 X 1.3 STUD,
BLK PU
11 6560-1072 A/R ADHESIVE, LOCTITE 49
14 6690-0001 1 BULLSEYE BUBBLE LEVEL
15 8527-0519-08 1 BASE PLATE, 30
16 8527-0520-0A 1 LOAD CELL ASSY, 10KG (APS160, APS15, APS8, APS12)
17 8527-0521-0A 1 LOAD CELL ASSY, 15KG (APS10, APS20)
18 8527-0521-1A 1 LOAD CELL ASSY, 15KG (APS30)
19 8527-0522-0A 1 LOAD CELL ASSY, 30KG (APS70)
20 8527-0523-08 1 BASE PLATE, 150
21 8527-0524-0A 1 LOAD CELL ASSY, 100KG (APS150)
22 8527-0527-08 1 BASE PLATE, 70
23 8527-0528-08 1 COVER, 12X14
24 8527-0529-08 1 TOP PLATE, 8/10/12
25 8527-0530-08 1 TOP PLATE, 160/15/20
26 8527-0531-08 1 TOP PLATE, 30
27 8527-0532-08 1 TOP PLATE, 70
28 8527-0533-08 1 TOP PLATE, 150
30 8527-C503-08 1 BASE PLATE, 8/10/12
31 8527-C504-08 1 COVER, 6X10
32 8527-C505-08 1 PCB COVER
33 8527-C513-08 1 BASE PLATE, 160/15/20
34 8527-C514-08 1 COVER, 10X10
A/R = AS REQUIRED
To Next Page
