“FCR3 three-phase controller +030222150 - rel. 1.3 - 12.01.2021
4.2 Advanced internal parameter
programming
The parameters are programmed via a serial link by expert and trained
personnel. This procedure for setting the parameters allows more speci c
functions to be selected than those available with manual setting.
Function Variable State Description
Enable output override
WE
CO.1
0 : Disable override of variable EOVR
1 : Enable override of variable EOVR
Reset default values
FDEF
CO.7
0 : No action
1 : Reset default values (one time)
Save parameters
SAVE
CO.8
0 : No action
1 : Save the values to memory (one time)
Override input variable
IOVR
CO.9
0 : No action
1 : Enable override of input variable and use INMEM
Logic of digital inputs SW1+SW2
MODID
CO.10
0 : Normally closed
1 : Normally open
Override output variable
EOVR (1)
CO.11
0 : No action
1 : Enable override of output variable and use OUT MEM
Maximum temperature alarm threshold setting
TEMPALM+
HO.5
-30 -105 High temperature alarm value (integer with sign)
Minimum temperature alarm threshold setting
TEMPALM-
HO.6
-30 -105 Low temperature alarm value (integer with sign)
Input delay setting
DELAYINMEM
HO.8
0-100
Response time to an input step. The range of adjustment from 0-100%
(clockwise) corresponds to setting the time from 0-10 sec
Output in the event of alarms or timeout
ALMO
HO.9
0/1/2
Select the output voltage in the event of alarm or serial line timeout and
activate input override (0=0% , 1=50%, 2 = 100%)
Controller output from memory
OUTMEM
HO.10
0-100 Output voltage value in the case of override (EOVR=1)
Serial communication timeout
TIMOEOUTH|L
HR.11| HR.12
0-5 |0-255
Serial communication timeout beyond which the link LED goes o and if
input override is enabled, the ALMO output is activated (seconds)
Saving timeout
TIMESAVE
HO.13
0-255
Time for saving the parameters. After this time, if changes are made to the
parameters, these are saved to memory (minutes)
Tab. 4.e
(1) Modi able only if WE=ON
4.3 Default settings
Manual/FCR parameters
Function Manual Setting Parameter Modbus Default Manual setting
Select type of setting Dip S2.1 SEL DI.1 OFF Manual
Select type of analogue input Dip S2.2 None None OFF 0/10V
Select voltage/current input Dip S2.3 None None OFF Voltage
Select operating frequency Dip S2.4 HZFCR DI.2 OFF 50 Hz
Select operating curve Dip S2.5 LINFCR DI.3 OFF Linear
Selection input mode Dip S2.6 MINCUTFCR DI.4 ON Cut-o
Baud rate
Dip S2.7 BAUD1FCR DI.5 ON
19200 Baud
Dip S2.8 BAUD2FCR DI.6 OFF
Serial address Dip S1 SADDRFCR IR.1 1 Device Address = 1
Input delay setting TR3 DELAYFCR IR.2 100% 100% = 10 sec; TR3 = 0-100% is DELAY = 100% and real delay = 10 sec
Maximum setting TR2 MAXFCR IR.3 100% 100%=100%; TR2=0-100% is MAXFCR=100%
Minimum setting TR1 MINFCR IR.4 40% Position TR1 ==> 100% = 40% Vnom. (IR4=40%); MINFC=40%
Anaolg Input B/GND INFCR IR.6 0
Tab. 4.f
Note: The selection of memory parameters and manual setting is de ne
by the dip2.1 positioning: if ON = memory; if OFF = manual
Memory/Internal parameters
Function Parameter Modbus Default
Enable output override WE CO.1 0 Disabled
Select operating frequency HZMEM CO.2 0 50 Hz
Select operating curve LINMEM CO.3 0 Linear
Selection input mode MINCUTMEM CO.4 1 Cut-o
Reset default values FDEF CO.7 0 Disabled
Save parameters SAVE CO.8 0 No action
Override input variable IOVR CO.9 0 Disabled
Logic of digital inputs SW1+SW2 MODID CO.10 0 Normally closed
Override output variable EOVR CO.11 0 Disabled
Serial address SADDR MEM HR.1 0 No devices in default
Input delay setting DELAY MEM HR.2 100 10 sec
Maximum setting MAX MEM HR.3 100 100%
Minimum setting MIN MEM HR.4 40 40%
Maximum temperature alarm threshold setting TEMPALM+ HR.5 85 85°C
Minimum temperature alarm threshold setting TEMPALM- HR.6 -20 -20°C
Input control INMEM HR.7 0 0% O
Input delay setting DELAYINMEM HR.8 100 10 sec
Output in the event of alarms or timeout ALMO HR.9 0 0% O
Controller output from memory OUTMEM HR.10 0 0% O
Serial communication timeout TIMOEOUTL|H HR.11| HR.12 30 | 0 30 sec
Saving timeout TIMESAVE HR.13 5 5 minutes
Tab. 4.g
