MODID Digital input mode
Modbus address read/write coil 10
resolution
and unit of measure
1
range 0/1
default 0
Parameter, to determine the digital input logic, used to activate the alarm
when the digital input status (STID) represents the reverse situation
• MODID=0 normally closed input logic
• MODID=1 normally open input logic
EOVR Override output
Modbus address read/write (*) coil 11
resolution
and unit of measure
1
range 0/1
default 0
Parameter to overwrite the output using a value set in the memory
(OUTMEM)
• EOVR=0 no override
• EOVR=1 enable override
(*) Possibility to activeted the override only if parameter WE=1
SEL Select controller settings
Modbus address read discrete input
1 – Reading of Dip
S2.1
resolution
and unit of measure
1
range 0/1
default R
Selects which parameters are used to manage operation of the controller.
Manual from FCR panel, Internal from FCR memory
• SEL=0 Select manual from FCR panel (MAN) –
Use the variables with su x FCR
• SEL=1 Select internal from FCR memory (MEM)
Use the variables with su x MEM
HZFCR Select frequency from manual
Modbus address read discrete input
2 – Reading of Dip
S2.4
resolution
and unit of measure
1
range 0/1
default R
This parameter is used to select the operating frequency of the FCR
controller
• HZFCR=0 50 Hz
• HZFCR=1 60 HZ
LINFCR Select operating curve
Modbus address read discrete input
3 – Reading of Dip
S2.5
resolution
and unit of measure
1
range 0/1
default R
This parameter is used to select linear or quadratic control
• LINFCR=0 linear
• LINFCR=1 quadratic
MINCUTFCR Select minimum/cut-o mode
Modbus address read discrete input
4 – Reading of Dip
S2.6
resolution
and unit of measure
1
range 0/1
default R
This parameter is used to select how the controller responds to no control
signal (when INFCR = 0 or INMEM = 0).
• MINCUTFCR=0 minimum
• MINCUTFCR=1 cut-o
BAUD1FCR /
BAUD2FCR
Select baud rate
Modbus address read discrete input
5/6 – Reading of
Dip S2.7 /8
resolution
and unit of measure
1
range 0/1
default R
Parameter used to select the serial line baud rate
Value BAUD1FCR BAUD2FCR
9600 0 0
19.200 1 0
38400 0 1
ALRTMP Temperature alarm status
Modbus address read discrete input 7
resolution
and unit of measure
1
range 0/1
default R
Indicates activation of the temperature alarm based on the reading of the
sensor on the FCR and the set thresholds
• ALRTMP= 0 alarm deactivated red LED does not change
• ALRTMP= 1 alarm deactivated red LED  ashes
ALRPRC Probe short-circuited alarm
Modbus address read discrete input 8
resolution
and unit of measure
1
range 0/1
default R
This alarm indicates whether the temperature sensor is short-circuited.
When this alarm is activated, temperature alarm is activeatd in the same
time.
• ALRPRC= 0 alarm deactivated
• ALRPRC= 1 active alarm sensor short-circuited
ALRPRO Probe open alarm
Modbus address read discrete input 9
resolution
and unit of measure
1
range 0/1
default R
Indicates the temperature alarm disconected.
• ALRPRO= 0 alarm deactivated
• ALRPRO= 1 active alarm, sensor disconnected.
STID Status of inputs SW1 and SW2
Modbus address read discrete input 10
resolution
and unit of measure
1
range 0/1
default R
Indicates digital inputs SW1+SW2 state.
• STID=0 inputs open
• STID=0 inputs closed
ALRM Digital input alarm status
Modbus address read discrete input 11
resolution
and unit of measure
1
range 0/1
default R
Indicates activation of the alarm from digital inputs SW1 and SW2
• ALRM=0 alarm not active
• ALRM=1 alarm active
FCRON FCR status
Modbus address read discrete input 12
resolution
and unit of measure
1
range 0/1
default R
Indicates the status of the FCR controller
• FCRON=0 controller o
• FCRON=1 controller on
