“FCR3 three-phase controller” +030222150 - rel. 1.3 - 12.01.2021
TEMPER Temperature probe
Modbus address
read input register 5
Temperature probe reading
resolution and unit of
measure
1
range -20 to 100
default R
Temperature probe reading expressed in integer with sign
IN FCR Analogue input value
Modbus address
read input register 6
Analogue signal reading
resolution and unit of measure 1%
range 0 to 100
default R
Analogue control value at FCR board: 0 to 100%
OUTMIN Minimum output value
Modbus address read input register 7
resolution and unit of measure 1%
range 0 to 40%
default R
Minimum output voltage value. 0-40%.
OUTMAX Maximum output value
Modbus address read input register 8
resolution and unit of measure 1%
range 50 to 100%
default R
Maximum output voltage value. 50-100%.
OUTFCR Current output
Modbus address read input register 9
resolution and unit of measure 1%
range 0, OUTMIN to OUTMAX
default R
Current output voltage value: 0, OUTMIN to OUTMAX.
IN Processed input value
Modbus address read input register 10
resolution and unit of measure 1%
range 0 to 100
default R
Analogue control value after processing and delay: 0 to 100%.
OUTREAL
Real Output Variable
Modbus address read input register 11
range 0 to 100
default R
Value of real output regulator (in relation to all setted paramters)
