9
ENG
ir33 universale +030220801 - rel. 2.1 - 21.06.2011
USB/RS485 converter (CVSTDUMOR0)
The USB/RS485 converter is an electronic device used to interface a
RS485 network to a personal computer via the USB port.
Fig. 1.e
RS485 card (code IROPZSER30)
Used to connect the DN33 via the RS485 serial network to the PlantVisor
supervisory system.
Fig. 1.f
Analogue output module (code CONV0/10A0)
Converts the PWM signal for solid state relays (SSR) to a standard 0 to 10
Vdc or 4 to 20 mA signal. For models IR/DN33A7**** and IR33D7**** only.
Fig. 1.g
ON/OFF module (code CONVONOFF0)
This module converts a PWM signal for solid state relays to an ON/OFF
relay output. Useful when the IR/DN33A7**** or IR33D7**** controller
needs to be used with one or more outputs to control solid state relays,
and at the same time one or more ON/OFF outputs are required for the
control functions or alarms.
Fig. 1.h
