7. TABLE OF PARAMETERS
In the parameter tables, repeated parameters highlight di erent settings on the models with universal inputs compared to the models with temperature
inputs only.
Par. Description Note Def Min Max UoM Type CAREL
SPV
ModBus® R/W Icon
St1 Set point 1 20 (68) c21 c22 °C (°F) A 4 4 R/W
St2 Set point 2 40 (104) c23 c24 °C (°F) A 5 5 R/W
c0 Operating mode
1= direct
2= reverse
3= dead zone
4= PWM
5= alarm
6= direct/reverse from digital input 1
7= direct: set point and di erential from digital input 1
8= reverse: set point and di erential from digital input 1
9= direct and reverse with distinct set points.
2 1 9 - I 12 112 R/W
P1 Set point 1 di erential 2 (3,6) 0.1 (0,2) 50 (90) °C (°F) A 6 6 R/W
P2 Set point 2 di erential 2 (3,6) 0.1 (0,2) 50 (90) °C (°F) A 7 7 R/W
P3 Dead zone di erential 2 (3,6) 0 (0) 20 (36) °C (°F) A 8 8 R/W
P1 Set point 1 di erential 2 (3,6) 0.1 (0,2) 99,9 (179) °C (°F) A 6 6 R/W
P2 Set point 2 di erential 2 (3,6) 0.1 (0,2) 99,9 (179) °C (°F) A 7 7 R/W
P3 Dead zone di erential 2 (3,6) 0 (0) 99,9 (179) °C (°F) A 8 8 R/W
c4 Authority.
Validity: mode 1 or 2
0.5 -2 2 - A 9 9 R/W
c5 Type of control
0=ON/OFF (Proportional)
1=Proportional+Integral+Derivative (PID)
0 0 1 - D 25 25 R/W
c6 Delay between activation of 2 di erent relay outputs
Validity: c0≠ 4
5 0 255 s I 13 113 R/W
c7 Minimum time between activation of the same relay output
Validity: c0 ≠ 4
0 0 15 min I 14 114 R/W
d1 Minimum time between deactivation of 2 di erent relay
outputs
Validity: c0 ≠ 4
0 0 255 s I 15 115 R/W
c8 Minimum relay output o time
Validity: c0 ≠ 4
0 0 15 min I 16 116 R/W
c9 Minimum relay output on time
Validity: c0 ≠ 4
0 0 15 min I 17 117 R/W
c10 Status of control outputs on circuit 1 in the event of probe 1
alarm
0=All outputs OFF
1=All outputs ON
2=“Direct” outputs on, “reverse” outputs o
3=“Direct” outputs o , “reverse” outputs on”
0 0 3 - I 18 118 R/W
d10 Status of control outputs on circuit 2 in the event of probe 2
alarm
see c10
0 0 3 - I 112 212 R/W
c11 Output rotation
0=Rotation not active
1=Standard rotation (on 2 or 4 relays)
2=2+2 rotation
3=2+2 rotation (COPELAND)
4=Rotate outputs 3 and 4, do not rotate 1 and 2
5=Rotate outputs 1 and 2, do not rotate 3 and 4
6=Rotate separately pairs 1,2 (between each other) and 3,4
(between each other)
7=Rotate outputs 2,3,4, do not rotate output 1
8=Rotate outputs 1 and 3, do not rotate 2 and 4
Validity: c0=1,2,7,8 and c33=0
0 0 8 - I 19 119 R/W
c12 PWM cycle time 20 0,2 999 s A 10 10 R/W
c13 Probe type
0=Standard NTC range (-50T+90°C)
1=NTC-HT enhanced range (-40T+150°C)
2=Standard PTC range (-50T+150°C)
3=Standard PT1000 range (-50T+150°C)
0 0 3 - I 20 120 R/W
