8. PARAMETERS TABLE “MASTER” ELECTR. PANEL
Mask Display description Notes Def. UOM Min Max Value description Type R/W
Press UP/DOWN to display the Info icon and then press Enter to access the Information quick menu
Info
i01 Humidifi er size 0,5 kg/h 0,5 18 I R
Next wash - h IR
i02 Work hours counter - h IR
Machine hours counter - h IR
i03 Water level sensor state - - Low High Low ¦ Work ¦ High I R
i04 Dip-switch state R
A. On/Off Unit
A01 On/Off
Enable No - No Yes No ¦ Yes D R/W
Autotest Yes - No Yes No ¦ Yes D R/W
Manual wash No - No Yes No ¦ Yes D R/W
Max Prod 100 % 10 100 I R/W
B. Setpoint
B01 Setpoint Fa01=reg. with probe 50.0 rH % / °C 10.0 80.0 I R/W
Limit 90.0 rH % 0 100.0 I R/W
C. Clock/ Scheduler
C01 Clock
Day Monday day Monday Sunday - I R
Date 01/01/2015 dd/mm/yy --/--/---- --/--/---- dd/mm/yy I R/W
Hour hh:mm hh:mm 00:00 23:59 hh:mm I R/W
C02 Clock
DST (daylight saving time): Enable - Enable Disable D R/W
Transition time 60 min 0 240 I R/W
Start: Last - First Last First ¦ ...¦ Fourth¦ Last I R/W
Sunday day Monday Sunday Monday ¦ ...¦ Sunday ¦ *** I R/W
in March month January -- January ¦ ... ¦ December ¦ - - I R/W
at 2.00 hour 0.00 23.00 I R/W
End: Last - First Last First ¦ ...¦ Fourth¦ Last I R/W
Sunday day Monday *** Monday ¦ ...¦ Sunday I R/W
in October month January December January ¦ ... ¦ December I R/W
at 3.00 ora 0.00 23.00 I R/W
C03 Scheduler
Enable scheduler ? No - No Yes No ¦ Yes D R/W
C04 Time bands (press Enter and UP/DOWN to check the box)
Day Monday - Monday Sunday Monday ¦ ...¦ Sunday I R/W
Time 1 hh/mm 00:00 23:59 I R/W
Off -Off On+Set Off ¦ On ¦ On +Set I R/W
Humidity set point %rH 0 100 I R/W
Time 2 hh/mm 00:00 23:59 I R/W
Off -Off On+Set Off ¦ On ¦ On +Set I R/W
Humidity set point %rH 0 100 I R/W
Time 3 hh/mm 00:00 23:59 I R/W
Off -Off On+Set Off ¦ On ¦ On +Set I R/W
Humidity set point %rH 0 100 I R/W
Time 4 hh/mm 00:00 23:59 I R/W
Off -Off On+Set Off ¦ On ¦ On +Set I R/W
Humidity set point %rH 0 100 I R/W
Time 5 hh/mm 00:00 23:59 I R/W
Off -Off On+Set Off ¦ On ¦ On +Set I R/W
Humidity set point %rH 0 100 I R/W
Time 6 hh/mm 00:00 23:59 I R/W
Off -Off On+Set Off ¦ On ¦ On +Set I R/W
Humidity set point %rH 0 100 I R/W
D. Master/Slave
Slave Manager
E. Data logger
E01 Data logger
N° - - 001 50 Nr. alarm I R
Hour - hour : min 00:00 23:59 Time of alarm activation I R
Date - dd : mm : yy 01 : 01 : 00 01 : 01 : 00 Date of alarm activation I R
F. User
User menu
a. Regulation
Fa01 Regulation
Regulation type Probe rH%+limit
rH%
- On/Off Probe T+Limit
rH%
On/Off ¦ Ext.regulator ¦ Ext.
regulator+limit rH% ¦ Probe rH% ¦
probe rH%+Limit rH% ¦ Probe T ¦
Probe T+Limit rH%
I R/W
Unit of measure °C-Kg/h °C-Kg/h °F-lb/h °C-Kg/h ¦ °F-lb/h D R/W
Fa02 Regulation
Max Prod 100 % 10 100 I R/W
Max Prod 100 % 10 100 I R/W
Min Prod 10 % 0 100 I R/W
Fa03 Regulation
Ambient probe Analog - Analog HYHU000000 Analog ¦ HYHU000000 D R/W
