lb-05046-03-EN Pag.6 22/01/2014
GENERAL CHARACTERISTICS
MACHINES IN SELF CONFIGURATION (see exploded view manual for code number)
Functions are absent or disabled by software:
steam wand: absent
extra milk function by pushing the cappuccino/latte dose key: disabled by sw
function to stop the dose delivery by pushing a dose key: disabled by sw
function to switch off the machine by pushing Shift and then Info keys: disabled by sw
Included features:
Kit to block the drip tray
Kit to block the decaf door
Recommended optionals:
Lock for beans hoppers and product canisters
Lock for the coffee grounds bin, placed instead of the missing steam wand OR
Direct coffee grounds.
Materials used:
- Stainless steel for boiler
- Teflon/Copper for hydraulic tubes
- Aluminium with stainless steel lining for the brewing group
- Plastic for grinder with conic grinder blades
- Other accessories in food plastic which are in contact with the ground coffee or drink
- Plastic for working area and cups tray
- Painted metal or stainless steel for machine body.
Number of coffee dispensing groups 1
Number of milk frother 1
Number of grinders 1or2
Number of product containers/mixer 1
Hot water dispenser 1
Maximum quantity of dispensable
drinks per minute
4 Espressos - 2 Large Coffee -2 Large Cappuccinos - 2 Large
Chocolate – 2 Tea cups
Hot water capacity per hour (lt) 30
Machine width (mm) 325
Machine height (mm) 814
Machine depth (mm) 561
Net weight (Kg) 50
Coffee hopper capacity (gr) 1300
Instant canister capacity (lt) 4
Coffee Boiler capacity (lt) 1
Steam Boiler capacity (lt) 1,8
Coffee Boiler resistor (W) 1800/2500
Steam Boiler resistor (W) 2000/2800
Voltage (V) 200V-1+N – 50/60Hz
220V-1+N – 50/60Hz
230V-1+N – 50/60Hz
240V-1+N – 50/60Hz
230V-3 – 50/60Hz
400V-3+N – 50/60Hz
Brewer group resistor PTC (W) 70
