Carimali Optima Silver - Electric and Hydraulic Connections; Main Power and Fuse Connections

lb-05046-03-EN Pag.8 22/01/2014
ELECTRIC - HYDRAULIC CONNECTION
200V-1+N-50/60HZ
400V-3+N-50/60HZ
200V-3 -50/60HZ
230V-1+N-50/60HZ 230V-3 -50/60HZ
120V-1+N-50/60HZ
H2O IN
(1-5 Bar)
H2O OUT
WATER SOFTNER
WATER FILTRE



