lb-05046-03-EN Pag.66 22/01/2014
CONTROL UNIT LEGEND
A) MASTER BOARD
code no. 96.00841 (see electric diagram)
Functions of the fuses:
FU1 value: 4 A 250V. type: D : fuse for mixer motor 1
FU2
value: 4 A 250V. type: D : fuse for mixer motor 2
Please Note :
THE OTHER ACTUATORS ARE PROTECTED FROM ELECTRONIC FUSES ( PTC – VDR ).
B) MASTER BOARD LED LEGEND
LED1 LD1 - Vcc : ( red colour) 5 V. DC power supply for microprocessor and electronic component
LED LD2 - VH: ( red colour) 24 V. DC main power supply for master board
LED LD3 - VREG : ( red colour) 12 V. DC power supply for triac and on/off relays
