6540 Series Operations Manual Rev_I 1/12/2016 11
Power Requirements
The Power Cord of this chamber is equipped with a grounded plug to minimize the possibility of electrical
shock from the chamber. CARON recommends that the chamber have a dedicated wall outlet. Verify
correct power supply required for particular unit.
Models 6540-1 and 6545-1
Plug is NEMA configuration 5-15P for 115V, 15A (Hubbell 5266C).
Models 6540-2 and 6545-2
Plug is NEMA configuration 6-15P for 208/230V, 15A (Hubbell 5666C).
Models 6540-3 and 6545-3
Modular cord set has continental European CEE 7/7 10/16A plug. Connector type is IEC 60320 C14 (or C20
with options).
