Carrier SmartVu control User Manual

SRDC-UG-2-14-000
REVISION
DATE
PAGE
19 Series Carrier®
SmartVu
TM
–
Controls IOM
2.3
Dec 4, 2020
122 OF 168
122
Alt-175
ALT-175 Master Slave
Alert - ncorrect Master
Control Type
Manual
As above
Check master control type
Alt-176
ALT-176 Master Slave
Alert - No
Communication Master /
Slave
Automatic
As above
Check communication between master and
slave, wiring, etc.
Alt-179
ALT-179 Master Slave
Alert - aster CCN Write
Rejection
Manual
As above
Check CCN communication, hardware and
software
Alt-180
ALT-180 Master Slave
Alert - Slave address not
slave
Manual
As above
Check master slave configurations
ALT-181
ALT-181 Loss
Communication with
AHF GDCB 1
Manual
As above
Check the communication configurations
between the main control board and GDCB1
board, and the cables, etc.
ALT-182
ALT-182 Loss
Communication with
AHF GDCB 2
Manual
As above
Check the communication configurations
between the main control board and GDCB2
board, and the cables, etc.
ALT-183
ALT-183 Loss
Communication with
AHF GDCB 3
Manual
As above
Check the communication configurations
between the main control board and GDCB3
board, and the cables, etc.
ALT-184
ALT-184 Loss
Communication with
AHF GDCB 4
Manual
As above
Check the communication configurations
between the main control board and GDCB4
board, and the cables, etc.
ALT-185
ALT-185 AHF GDCB 1
Start Failure
Manual
As above
Check AHF GDCB board 1 and the related
configurations
ALT-186
ALT-186 AHF GDCB 2
Start Failure
Manual
As above
Check AHF GDCB board 2 and the related
configurations
ALT-187
ALT-187 AHF GDCB 3
Start Failure
Manual
As above
Check AHF GDCB board 3 and the related
configurations
ALT-188
ALT-188 AHF GDCB 4
Start Failure
Manual
As above
Check AHF GDCB board 4 and the related
configurations
ALT-189
Process Alert - Low Oil
Supply Temperature
Manual
As above
If oil supply temperature is less than the 95
F during chiller is running and oil exv is
enabled
ALT-190
AHF FAULT
Manual
As above
Receive the fault state
ALT-191
Loss Communication
with AHF
Manual
As above
Check the communication with AHF every
1s, if no response, it will alert
6.5. Event States
A event state is a specific set of conditions which the controller may encounter when controlling the
chiller. Event states are predictable and repeatable and represent known states of the control. If the
control is in a particular state, there is a unique message associated with that state. The event states
message are displayed on default screen of control panel.
Event No.
Description of event state
1
Chiller Off
2
Chiller Tripout
3
Pumpdown/Lockout
4
Terminate Pumpdown/Lockout
5
Guide Vane 1 Calibration
6
Quick Test in Progress
7
Ice Build Done
8
Ice Build in Progress
9
Free Cooling in Progress
