5.3. Chiller Start-up Sequence
5.3.1. Prestart Check
Once start-up begins, the controller performs a series of pre-start tests to verify that all pre-start alerts
and safeties are within the limits.
PRESTART ALERTCONDITION
State
Number
Alarm or
Alert
STARTS IN 12 HOURS >= 8
100
Alert
OIL SUMP TEMP <= 140F AND OIL SUMP TEMP <= EVAP_SAT +
50F
101
Alert
CONDENSER PRESSURE >= COND PRESS OVERRIDE - 20 PSI
102
Alert
Number of recycle restart in the last 4 hours is greater than 5
103
Alert
3
"LOCKOUT
"
Lockout in Controls Test is active
OFF
4mA
4
"RECYCLE
"
Recycle shutdown completed on
low load in effect; non-fault
condition
ON
12mA
5
"TRIPOUT"
Shutdown completed due to alarm
fault condition.
OFF
8mA
6
"TIMEOUT"
Start-to-start or stop-to-start timer is
actively counting down; non-fault
condition
ON
12mA
7
"PRESTAR
T"
Prestart check is active
ON
12mA
8
"STARTUP
"
Normal Startup in progress
ON
12mA
9
"AUTORST
"
Auto Rapid pending in progress
ON
12mA
10
"RAMPING
"
Ramp loading in progress
ON
20mA
11
"RUNNING
"
Normal running mode, no override
and not in demand
ON
20mA
12
"OVERRID
E"
Running with Override active
ON
20mA
13
"DEMAND"
Running with Demand Limit Active;
ON
20mA
14
"SHUTDO
WN"
Shutdown compressor in progress
ON
12mA
15
“FREECOO
L”
Free cooling in progress
OFF
4mA
16
“CONDFLS
H”
Condenser Flush in progress
OFF
4mA
