Carrier SmartVu control User Manual

SRDC-UG-2-14-000
REVISION
DATE
PAGE
19 Series Carrier®
SmartVu
TM
–
Controls IOM
2.3
Dec 4, 2020
164 OF 168
164
22
Q_DMPCL
OFF_ON
OFF
-
ECO DMP VLV Close
23
Q_ALM
OFF_ON
OFF
-
Alarm Output
24
Q_ALE
OFF_ON
OFF
-
Alert Output
25
Q_CDWP
OFF_ON
OFF
-
Condenser Water Pump
26
CDW_FLOW
NO_YES
NO
-
Condenser Water Flow
27
CDW_DT
-22.22 to 136.11
-40 to 245
0.00
0
^C
^F
Condenser Water Delta T
28
Q_CHWP
OFF_ON
OFF
-
Chilled Water Pump
29
CHW_FLOW
NO_YES
NO
-
Chilled Water Flow
30
CHW_DT
-22.22 to 136.11
-40 to 245
0.00
0
^C
^F
Chilled Water Delta T
31
Q_LLCEXV
0 to 100
0
%
Liquid Level EXV
32
Q_VSSV
OFF_ON
OFF
-
ECO Vapor SV
33
Q_LQBP
4 to 20
4
mA
ECO LBP VLV mA
34
Q_FCMODE
OFF_ON
OFF
-
Free Cooling Mode
35
Q_LOWFAN
OFF_ON
OFF
-
Low Speed Tower Fan
36
Q_HIFAN
OFF_ON
OFF
-
High Speed Tower Fan
37
Q_TRIPR
OFF_ON
OFF
-
Shunt Trip Relay
38
QVFDLOCK
OFF_ON
OFF
-
Danfoss VFD Interlock
*Depends on the selected language (English by default).
QCK_DV - 19DV Quick Test
Name
Range
Default
Unit
Displayed text*
1
QCK_TEST
DSABLE_ENABLE
DSABLE
-
Quick Test Enable
2
Q_GV2POS
0 to 100
0
%
Guide Vane 2 Pos
3
Q_CONDSV
OFF_ON
OFF
-
Cond CV (DV Lube Sled)
