Carrier SmartVu control User Manual

SRDC-UG-2-14-000
REVISION
DATE
PAGE
19 Series Carrier®
SmartVu
TM
–
Controls IOM
2.3
Dec 4, 2020
166 OF 168
166
2
GV1_CAL
DSABLE_ENABLE
DSABLE
-
GV1 Calibration Enable
3
GV1_STAT
0 to 2
0
-
GV1 Calibration Status
4
blank
-
-
-
No Calib Or Failure=0,
5
blank
-
-
-
Progress=1, Completed=2
6
GV1_OHM
-
0
-
Guide Vane 1 Actual Ohms
7
GV1_MAXO
-
0
-
Guide Vane 1 Ohms 100%
8
GV1_MINO
-
0
-
Guide Vane 1 Ohms 0%
9
GV1_MAF
-
0
mA
Guide Vane 1 Actual mA
10
GV1_MAXA
-
0
mA
Guide Vane 1 mA 100%
11
GV1_MINA
-
0
mA
Guide Vane 1 mA 0%
12
GV2_CAL
DSABLE_ENABLE
DSABLE
-
GV2 Calibration Enable
13
GV2_STAT
0 to 2
0
-
GV2 Calibration Status
14
blank
-
-
-
No Calib Or Failure=0,
15
blank
-
-
-
Progress=1, Completed=2
16
GV2_MAF
-
0
mA
Guide Vane 2 Actual mA
17
GV2_MAXA
-
0
mA
Guide Vane 2 mA 100%
18
GV2_MINA
-
0
mA
Guide Vane 2 mA 0%
19
HGBP_CAL
DSABLE_ENABLE
DSABLE
-
EC/HG VLV Calib Enable
20
HGBP_ST
0 to 2
0
-
EC/HG VLV Calib Status
21
blank
-
-
-
No Calib Or Failure=0,
22
blank
-
-
-
Progress=1, Completed=2
23
HGBP_AMA
-
0
mA
EC/HG VLV Actual mA
24
HBP_MAXA
-
0
mA
EC/HG VLV mA 100%
25
HBP_MINA
-
0
mA
EC/HG VLV mA 0%
26
DMP_CAL
DSABLE_ENABLE
DSABLE
-
ECO DMP VLV Calib Enable
27
DMP_ST
0 to 2
0
-
ECO DMP VLV Calib Status
